Quick Details

  • Place of Origin: Hebei, China (Mainland)
  • Brand Name: Copper Bridge
  • Model Number: AWS E6013 E7018
  • Material: Steel,H08A
  • Length: 300mm,350mm,400mm
  • Operating Current: 50-90,90-130,130-210(A)
  • Welding Current: AC/DC
  • Operating Temperature: 50-240
  • Diameter: 2.5mm,3.2mm,4.0mm
  • Application: low carbon steel
  • Advantage: small spatters, easy restrike arc,slag easy to remove
  • Type: a high titania potassium
  • Colour: grey, white,green,red
  • Coated: rutile sand coated
  • Business type: manufacturer
  • Delivery time: 20 days
  • Sample: free supply
  • Certificate: CE , CCS , ISO9001 , BV , TUV , SONCAP
  • OEM: accepted
  • Trade Terms: FOB,CIF,EXW

Packaging & Delivery

Packaging Details welding electrodes e6013
Size (2)Packing (Net weight) (3) Measurement 2.5*300mm 2.5kgs/box,8boxes/carton=20kgs 0.009CMB/Carton, 2.2Tons/CBM 3.2*350mm 5kgs/box, 4boxes/carton=20kgs 0.009CMB/Carton, 2.2Tons/CBM 4.0*400mm 5kgs/box, 4boxes/carton=20kgs 0.009CMB/Carton, 2.2Tons/CBM 5.0*400mm 5kgs/box, 4boxes/carton=20kgs 0.009CMB/Carton, 2.2Tons/CBM

Manufacturer of Copper Bridge brand mild steel welding electrodes e6013

FEATURES:

 Welding electrodes e6013 is carbon steel welding electrode covered with a high titania potassium type coating. Both AC and DC can be applied, and it is applicable for all-position welding, including vertical-down welding.

It shows a very good welding performance with small spatters, easy restrike arc,very good weld shape and slag easy to remove.



APPLICATIONS:

Welding electrodes e6013 suitable for welding low carbon steel structures and low carbon galvanized plate especially applicable for vertical-down welding

and intermittent welding,



Chemical Composition of Deposited Metal(%)

Welding electrodes e6013

Chemical Composition

C

Mn

Si

S

P

Guarantee Value

0.12

0.3~0.6

0.35

0.035

0.040



Mechanical Properties of Deposited Metal

Test Item

Rm(MPa)

ReL(Mpa)

A(%)

KV2(J)

KV2(J)

Guarantee Value

420

330

17

-(normal temperature)

-(0°C)

General Result

460~540

340

18~26

50~80

47



Reference Current(AC,DC)

Electrode diameter(mm)

Φ2.5

Φ3.2

Φ4.0

Φ5.0

Welding current(A)

50~90

90~130

130~210

170~210



PACKAGE:

welding electrodes e6013



Size: 2.5MM X 300MM

 (Packing : 2.5kg/inner boxes  8 boxes/cartons=20kg)



Size: 3.2MM X 350MM

(Packing: 5.0kg/inner boxes  4boxes/cartons=20kg)



Size: 4.0MM X 400MM

Packing: 5.0kg/inner boxes  4boxes/cartons=20kg

above package is the detail international  package .





Advantages



PRODUCT:

PACKAGE:





Production Flow





Certifications



As a professional welding electrode factory in China, our main products are series of welding electrodes and welding wires.

We have two our own brands“Copper Bridge”“Forever”.

Best price with good quality is our mainly business principles for long time.
