Cast Iron Electrode Z308 of good quality

FOB Reference Price:Get Latest Price
US $670-750 / Metric Tons | 10 Metric Ton/Metric Tons (Min. Order)
Diameter:
2.5mm, 3.2mm, 4.0mm
Length:
300mm, 350mm, 400mm
Customization:
Customized logo (Min. Order: 27 Metric Tons)
Customized packaging (Min. Order: 27 Metric Tons)

More

Graphic customization (Min. Order: 27 Metric Tons) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Hebei, China (Mainland)
Brand Name:
Copper Bridge
Model Number:
Z308
Material:
Cast Iron
Operating Current:
AC DC
Welding Current:
60-90,90-120,120-150
Operating Temperature:
international tempreture
Application:
carbon steel structure
Fe composition:
<=8
type:
manufacturer
color:
red green grey black blue
Supply Ability
Supply Ability:
350 Metric Ton/Metric Tons per Week welding electrodes
Packaging & Delivery
Packaging Details
Dia 2.5mm:2.5kg/box, 8boxes/ctn, 20kg/ctn Ctn Size:32*18*16cm;
Dia3.2mm: 5kg/box,4boxes/ctn, 20kg/ctn Ctn Size:37*18*13cm;
Dia4.0mm:5kg/box, 4boxes/ctn,20kg/ctn Ctn Size:42*17*12cm..
Port
Xingang Port, China
Lead Time :
Quantity(Metric Tons) 1 - 5 >5
Est. Time(day) 20 To be negotiated

Cast Iron Electrode Z308

It is a graphite type electrode with pure nickel core. Suitable for repairing of welding various cast irons

The weld metal zone has a few inclination to harden, then matching is easy.

The color can not match the base metal.

Chemical Composition.

C<=2.

Si<=2.5

Ni>=90

Fe<=8

Description

Types Of ElectrodesIntroductionUses

Model: CB-J421



GB: E4313



AWS: E6013

It is a kind of carbon steel electrode with titania type coating.

AC/DC.

All position welding.

It has excellent welding performance,

excellent operating performance,

easy reignition, stable arc,

beautiful appearance of weld.

For welding low carbon steel structures, especially suitable for welding on thin plates and cometic welding which requires the weld beads to be beautiful and glossy.

Model: CB-J425



GB: E4311



AWS: E6011

It is a kind of carbon steel electrode with cellulose potassium type coating.

AC/DC.

It has excellent welding performance, beautiful appearance after vertical downward welding, fewer slags and high welding efficiency.

Suitable for butt welding, fillet welding and lap welding on thin plates, such as low carbon steel structures like flues of power stations, air ducts, transformer oil tanks, hulls, exterior panels of cars, etc.

Model: CB-J507



GB: E5018



AWS: E7018

It is a kind of carbon steel electrode with low hydrogen type coating.

AC/DC.

It has excellent welding performance,

easy reignition, stable arc,

beautiful appearance of weld.

Used for welding carbon steel and low alloy steel structures, such as 16Mn, etc.

Chemical Composition of Deposited Metal (%)

AWSChemical CompositionCMnSiSP
E6013Guarantee Value≤0.120.30-0.60≤0.35≤0.035≤0.040
E6011Guarantee Value≤0.200.30-0.60≤0.30≤0.035≤0.040
E7018Guarantee Value≤0.12≤1.60≤0.75≤0.035≤0.040

Mechanical Properties of Deposited Metal (%)

AWSTest ItemRm(Mpa)Rel(Mpa)A(%)KV2(J)
E6011

Guarantee Value



General Result

≥420



440-450

≥330



≥340

≥22



22-30

≥27(-30°C)



50-90(-30°C)

E6013

Guarantee Value



General Result



≥420



460-540



≥330



≥340



≥17



18-26



-(0°C)



≥47

E7018 Guarantee Value ≥490 ≥400 ≥22 ≥27(-30°C)

Reference Current(AC, DC)

AWSElectrode Diameter(mm)φ2.5φ3.2φ4.0φ5.0
E6013Welding Current(A)50-9090-130130-210170-230
E6011Welding Current(A)30-5080-100110-130150-200
E7018Welding Current(A)60-10080-140110-210160-230
